TM80 Automatic Single Head Tube End Forming Machine
Back
Features
Basic Parameters
Video
Industry Applications
Contact Us
Features
1.This fully automated machine is designed for high efficiency, optimizing tube forming operations with precision and minimal downtime.
2.The hydraulic-powered tube clamping and end forming mechanism guarantees smooth, consistent results across various materials and production conditions.
3.The intuitive PLC touch screen provides easy navigation between automatic and manual modes, allowing operators to quickly adjust settings for different tasks.
4.It supports a wide range of end forming shapes, including concave-convex, elongated, flat, square, tapered, V-shaped, and open slot, making it adaptable to various manufacturing needs.
5.Premium mechanical components ensure the machine operates with excellent stability, reducing the risk of malfunction and extending its service life.
6.The die change process is designed for simplicity, enabling quick adjustments and minimizing production delays.
7.Certified to meet CE and ISO9001 standards, this machine complies with rigorous international quality and safety regulations, ensuring reliable performance in any industrial setting.
Parameter table
Main Technical Parameter
| Name | TM-80 | TM-80-2 (2 workstations) |
| Max. End Forming Capacity | Φ80x3mm | Φ80x3mm |
| Max. End Forming Length | 150mm | 150mm |
| Reduction time | 100/8-10mm/s | 100/8-10mm/s |
| Max. Hydraulic Pressure | 16Mpa | 16Mpa |
| Motor Power | 7.5kw | 7.5kw |
| Dimension of machine | 2900x700x1700mm | 3200x900x1700mm |
| Weight of the machine | 1500kg | 1800kg |
