High Precision Forming Fully Automatic Taper Tube Reducing Machine
Back
Features
Basic Parameters
Video
Industry Applications
Contact Us
Features
High Precision Forming：The machine delivers precise, smooth tapers and shrink-formed ends, eliminating surface imperfections and distortion for high-quality results.
Automated Operation：It seamlessly integrates feeding, forming, and unloading functions, ensuring consistent performance and enhancing production efficiency.
Rapid Mold Switching：The system allows for quick mold changes, reducing downtime and accommodating a variety of mold types and product sizes.
Flexible Processing：This machine can easily adapt to different materials, tube thicknesses, and tapering requirements, providing versatility across multiple applications.
Sturdy Construction：Designed with durable, high-quality components, the machine ensures stable operation and extended service life, even under demanding conditions.
Material Compatibility：Compatible with a variety of metals, including steel, stainless steel, aluminum, and copper, it meets diverse tube processing needs.
Parameter table
Main Technical Parameter
| Model | FAZTM-50-300 | FAZTM-50-450 | FAZTM76-600 | FAZTM76-800 |
| Machine Model | 50×300 | 50×450 | 76×600 | 76×800 |
| Machine size(MM) | 1200×900×1200 | 1060×760×1160 | 1600×1300×1500 | 1900×1500×1500 |
| Mold Size(MM) | 300×42×44 | 450×42×44 | 600×60×50 | 800×60×50 |
| Processing range(MM) | Φ12-Φ50 | Φ12-Φ50 | Φ18-Φ76 | Φ18-Φ76 |
| Workpiece thickness(MM) | 0.68-1.5 | 0.68-1.5 | 1.0-2.0 | 1.0-2.5 |
| Forming length(MM) | 280 | 430 | 580 | 780 |
| Molding time(S/Second) | 45422 | 45422 | 45422 | 45422 |
| Main motor(KW) | 3 | 5.5 | 7.5-11 | 7.5-15 |
| The total weight of equipment(KG) | 1100 | 1300 | 3200 | 3800 |
| Packing size(L*W*H)(MM) | 1250×950×1300 | 1200×800×1350 | 1660×1350×1600 | 1960×1560×1750 |
| Accessories | Spindle Motor1, Control Box1, Servo Motor1, Cylinder4 | |||
