ZTM-50/60/76/114 Multi-Material Applicable Semi-Automatic Taper Tube Reducing Machine
Back
Features
Basic Parameters
Video
Industry Applications
Contact Us
Features
Material Compatibility：The machine is suitable for processing a variety of materials, including carbon steel, stainless steel, aluminum, alloy, copper, and brass.
Control and Operation：It features microcomputer control and hydraulic driving, with both automatic and manual operation modes available.
User Interface：The machine offers English or Chinese subtitles and a user-friendly man-machine interface for easy operation.
Stability and Performance：Equipped with linear slider rails, the machine ensures stable propulsion during operation.
Precision and Efficiency：It delivers high accuracy and efficiency, optimizing production processes.
Parameter table
Main Technical Parameter
| Specification | HS-ZTM-50-300 | HS-ZTM-50-450 | HS-ZTM-60-450 | ZTM-76NC | ZTM114NC |
| Max Tube Size (mm) | Φ50×3 | Φ50×2 | Φ60×2.5 | Φ76×2 | Φ114×2.5 |
| Max Processing Length (mm) | 280 | 440 | 450 | 450(can be customized) | 400(can be customized) |
| Pipe Thickness (mm) | 0.5-2.0 | 0.5-2.0 | 0.5-2.5 | 0.5-2.0 | 0.5-2.5 |
| Processing Times(s) | 7-30 | 7-30 | 7-30 | 7-30 | 60-120 |
| Spindle Speed (RPM) | 248 | 248 | 248 | 248 | 248 |
| Main Motor Power (kw) | 4 | 4 | 5.5 | 5.5 | 11 |
